SALIENT FEATURES For Fermenter in Ahmedabad, Fermenter in Baroda And Surat
Culture vessel made of s.s.316 – optional – s.s.304.
Autoclave able optional insitu sterilization.
Head plate made of s.s.316 detachable.
Various provision & ports as per requirements.
Modular & detachable control panel.
Built-in variable speed stirrer with electronic control.
Different type & size of impeller as per customers requirements.
Digital auto tune pid temperature control system – optional microprocessor or plc based.
Capacity available in various capacity – 2, 3, 5 & 10 liter.
Built-in safety features.
Provided with sight glass.
All digital controllers & pressure gauges will be provided with calibration certificate with traceability to national standard from our associate m/s. Nova calibration centre.Nova Instruments For Fermenter in Ahmedabad, Fermenter in Baroda, Fermenter in Surat
TECHNICAL SPECIFICATION :
CULTURE VESSEL
Autoclave able Glass or Stainless Steel 316 (Optional S.S. 304)
HEAD PLATE
Stainless Steel 316.
STIRRER
Variable speed with control.
TEMPERATURE CONTROL
Digital.
PORT
Provided on head plate.
CONTROL SYSTEM [DIGITAL PID CONTROL]
C A P A C I T Y
2 LITRE
3 LITRE
5 LITRE
10 LITRE
STANDARD SUPPLY:
Basic fermentor unit with 11 ports.
Motorized stirring system having variable speed from 300 to 1500 settable.
Built-in cooling coil for chilled water circulation (provision).
Pressure gauge.
Safety valve.
Steam release valve.
Air inlet & outlet with sterilizable 0.2 micron filter.
Pt-100 sensor.
Spare ports.
CONTROL PANEL:
Consisting of Mains Switch, Mains Indicator, Digital PID Controller, Digital RPM Indicator for stirring etc.
OPTIONAL PARAMETER:
pH Controller with Digital readout.
Anti foam controller with S.S. Probe.
Peristaltic Pump fixed speed for Acid base & nutrient – Set of 3.
Peristaltic Pump variable speed for Acid base & nutrient – Set of 3.
Peristaltic Pump fixed speed.
Peristaltic Pump variable speed.
D. O. Indicating controller with electrode.
OPTIONAL ACCESSORIES :
Chiller for below ambient temperature operation.
Air compressor with filter and accessories.
Disposable filter – Set (Sterile).
Computer control software with PC and Printer.
BOILER FOR STEAM GENERATION, DIFFERENT MODEL FOR DIFFERENT SIZE FERMENTOR OR REQUIRE STEAM TO BE PROVIDED BY CUSTOMER FROM THEIR BOILER.
NOTE :-
INDUSTRIAL SERIES FERMENTOR CAN BE SUPPLIED AS PER REQUIREMENTS OF FOTHER CAPACITY & APPLICATION PARAMETERS.
